| Use power |
AC100V ± 10V 50 / 60Hz (specify) |
| Output voltage |
AC0 ~ 50kV (both polarities between)
AC0 ～ 25KV (one side poles - between the ground) |
| Rating capacity |
500VA |
| Grounding scheme |
Intermediate grounding scheme |
| voltmeter |
Instructs the input voltage and the output voltage (2 range switching) input voltage measurement for 0 ~ 120V, 0 for output voltage measurement ~ 30kV (one side poles - between the earth), formula (2.5 grade) 0 ~ 60kV (between the electrodes) |
| Voltage boost |
3kV / sec speed automatic boost the output voltage of the (step-down is manual)
with the clutch (rise due to the manual, can fall) |
| External dimensions |
239 (D) × 279 (W) × 400 (H) |
| weight |
About 30kg |
| accessories |
Test code set Oil Cup manual case cover
|
