| Feature |
Advanced model equipping various functions such as input/output the angles and saving to USB flash drive. |
Simple standard model maintaining DTXA performance. |
| Accuracy |
±0.5％F.S.±1digit |
| Unit of measurement |
N-m, N-cm, kgf-m,kgf-cm, ozf-in, lbf-in (Unit switching is possible.)(*1) |
| Display |
4-digit |
| Display update |
16 times/ sec |
| Sampling rate |
Maximum 2000 data/ sec(*2) |
| Battery |
8 hours (2 hours full charge)(*3) |
| Safe overload rating |
Approx. 200%Approx. 200% |
| Operating Environment |
Temperature: 0 -40 degree Celsius Humidity: 20 -80%RH |
| Function |
Customized display(header and footer) / Peak hold(Clockwise and Counterclockwise)/Internal memory(1000 point data)）/ Comparator (OK or NG judgment)/Reversible display/ Sign inversion/ Zero clear timer/ +NG alarm/Off timer(Auto power off)/ Dumping/ Time display/ setting lock
|
|
1st2nd peak/Angle detection at torque peak value(*4) /Angle zero reset at selected torque(*4)
|
– |
| Output |
USB, RS232C, Mitutoyo digimatic (*5), 2 VDC analog output (D/A),Comparator 3 steps (-NG/OK/+NG), Overload alarm
|
|
Sub comparator 2 steps (output of large or small judgment), USB flash drive, Angle(displacement)
|
– |
| Overload warning |
Approx.110%F.S. (Warning message and alarm ) |
| External connecting switch |
SEND (a point of contact holding), Zero reset, Peak, ON/OFF setting |
| Weight |
Approx. 4.5kg (Including Standard table and Standard pins) |
| Dimensions |
Please refer to dimensions. |
| Accessory |
AC adapter, Inspection certificate, CD driver (including simple software for data logging), USB cable
|
| USB flash drive adapter（*6） |
－ |
| Applicable Table |
Please see Specification for Torque Gauge Table Attachment |
| Applicable Attachment |
Please see Specification for Torque Gauge/ Motorized Stand Attachment |
