Sierra was the first to introduce multivariable mass vortex flow meters to the market in the late 1990s with the InnovaMass "S-Series" product line--the 240S and 241S. The InnovaMass 240S inline version is a true workhorse in applications ranging from large pipes and ducts, to high pressure and saturated or superheated steam. The InnovaMass 241S is manufactured as a volumetric only version or a multivariable version
Accuracy:
Mass flow: +/- 1% of reading (liquids);
+/- 1.5% of reading (gas & steam)
Volumetric: +/- 0.7% of reading (liquids);
+/- 1% of reading (gas & steam)
Repeatability:
Mass flow: +/- 0.2% of full scale
Volumetric: +/- 0.1% of full scale
Temperature: +/- 0.2°F (+/- 0.1°C)
Pressure: +/- 0.05% of full scale
Density: +/- 0.1% of full scale
Rangeability up to 30:1
(accuracy maintained across entire range
Measures steam, gases and liquids
Pipe sizes from 0.5 to 8 inches (1.3 to 20.3 cm); up to 72 inches (2 m) available See 241S or next generation 241i
Flow range (30:1 Turndown):
Liquids:
1 ft/s (0.3 m/s) Velocity Minimum
30 ft/s (9.1 m/s) Velocity Maximum
Gas & Steam:
10 ft/s (3.05 m/s) Velocity Minimum
300 ft/s (91.5 m/s) Velocity Maximum
Process fluid temperature:
Standard: -40°F to 500°F (-40°C to 260°C)
High temperature (HT): up to 750°F (400°C)
Low temperature (CT): down to -330°F (-200°C)
Ambient temperature:
Operating: -5°F to 140°F (-20° to 60°C)
Storage: -40°F to 150°F (-40° to 65°C) 0 to 98%
relative humidity, noncondensing conditions
