Dimension:
|
210×68×27 mm
|
Standards
|
IEC 61672 Class 2
|
Contents:
|
Meter, microphone, windscreen, external power supply, calibration certificate, English manual
|
Application:
|
Noise On-line Monitoring, Connect to Noise Screen
|
Frequency:
|
20 Hz~12.5 kHz
|
Power Supply:
|
External power supply, Electricity boot
|
Product Weight:
|
0.3 kg
|
Measurement Range:
|
30~130 dBA
|
Meas. Upper Range:
|
>130 dB
|
Display:
|
128×64 OLED
|
A/D Bits:
|
32 kHz
|
Notes:
|
Analog AC/DC outputs for connection to an analyzer or recorder, RS-232 port
|
A, C, Z weighting; F, S, I weighting
|
Lp,Leq1s, Lmax, overrun indicator
|
Limited value can be set
|
Built-in hardware watchdog
|
