| Capacity |
1000N (100kgf) |
| Maximum height of a sample |
Please refer to “t” of Dimensions below. |
| Deflection at maximum load |
0.25mm or less
0.6 mm or less (Long stroke type) |
| Test speed |
0.5 to 600mm/min |
| Gauges that can be combined (*1) |
Force gauges, DPU series load cells |
| Function |
Manual mode, JOG mode, Cycle mode |
| Digital set up of speed, counter, timer |
| Digital set up of travel, automatic gear change at a selected change point |
| Control |
Emergency button, I/O control signal,
Motion control by force(*2), Overload prevention(*2)(*3) |
| Safety devices |
Stroke limit, emergency stop button |
| Power |
AC100V to 240V, free input |
| Size |
Please refer to dimensions |
| Weight |
Approx.23.5kg |
| Option |
Long stroke, Linear scale |
| Accessory |
Gauge mounting plate(GF-2), Power cable, Spare fuse,
Instruction Maunal, Tools, Cover
|
