| Visual inspection |
+ |
+ |
+ |
+ |
| Earth bond resistance I = 200 mA |
+ (0,01…19,99 Ω) |
+ (0,01…19,99 Ω) |
+ (0,01…19,99 Ω) |
+ (0,01…19,99 Ω) |
| Earth bond resistance I = 10 A |
- |
- |
- |
+ (0,001…1,99 Ω) |
| Insulation resistance U = 250 V |
- |
- |
+ (0,01…99,9 MΩ) |
+ (0,01…99,9 MΩ) |
| Insulation resistance U = 500 V |
+ (0,01…99,9 MΩ) |
+ (0,01…99,9 MΩ) |
+ (0,01…99,9 MΩ) |
+ (0,01…99,9 MΩ) |
| Alternative leakage current |
+ (0,01...19,9 mA) |
+ (0,01...19,9 mA) |
+ (0,01...19,9 mA) |
+ (0,01...19,9 mA) |
| Touch leakage current |
- |
- |
+ (0,001…4,999 mA) |
+ (0,001…4,999 mA) |
| Differential leakage current |
- |
- |
+ (0,10…19,9 mA) |
+ (0,10…19,9 mA) |
| IEC cord test (RISO, RPE, Polarity) |
+ |
+ |
+ |
+ |
| PRCD (trip time for IΔn: x1/x5; 0° and 180°) |
- |
- |
10 mA, 30 mA |
10 mA, 30 mA |
